Found a great SSD deal, but need a heatsink for PS5 compatibility? It's a cheap and quick process, and should take under 10 minutes to install.

Recommended Heatsinks (2025)

✅ PS5 Tested & Verified

SABRENT M.2 NVMe PS5 Heatsink | ~$15

MHQJRH M.2 2280 Double-Sided Heatsink | ~$10

SGTKJSJS M.2 Double-Sided Heatsink | ~$7

Heatsink Installation

This 45 second demo shows just how easy it is!

Done! For a few bucks and a minute of your time your SSD is PS5 compatible.

Installation In PS5

Install in PS5 (5 minutes)

Follow Sony's official process:

1. Prepare PS5 - Power off completely, unplug cables
2. Remove side panel - PS logo facing down, lift from bottom-right corner
3. Access expansion slot - Remove cover with Phillips screwdriver
4. Install SSD - Insert at angle, press down, secure with screw
5. Replace covers - Reinstall expansion cover and side panel
6. Format drive - Follow PS5 on-screen instructions

Troubleshooting

SSD not detected

• Reseat the SSD firmly
• Check screw is properly tightened
• Verify spacer is in correct position

Temperature warnings

• Check thermal pad contact
• Ensure heatsink is properly attached
• Consider upgrading to double-sided heatsink

Performance throttling

• Monitor temperatures during gaming
• Verify heatsink installation
• Check for dust buildup

Safety & Warranty

• ✅ Installing M.2 SSDs does NOT void PS5 warranty
• ✅ Touch metal object before handling components (static discharge)
• ✅ Never force components during installation
• ✅ Keep all screws and parts organized

Temperature Monitoring

• Ideal range: Under 70°C during gaming
• Warning range: 70-85°C (performance may throttle)
• Critical: Over 85°C (system protection activated)

Why These Heatsinks Work

All recommended heatsinks feature:

• Double-sided cooling - Heat dissipation from both SSD surfaces
• Proper dimensions - Guaranteed fit within PS5's constraints
• Quality thermal interface - Effective heat transfer
• Easy installation - No additional tools required

Frequently Asked Questions

Q: Can I use any M.2 heatsink? A: No. PS5 has strict size limits (11.25mm total thickness). Generic PC heatsinks often exceed this.

Q: Do I need thermal paste? A: No. The recommended heatsinks include thermal pads that are easier to install and work better for this application.

Q: How much does a heatsink help? A: Heatsinks can reduce SSD temperatures by 20-30°C, preventing throttling and extending drive life.

Q: Can I install multiple M.2 drives? A: PS5 has only one M.2 expansion slot. You can only install one additional drive.
